Kawasaki Z1000SX - Owner's Manual > Meter Instruments

General Information / Meter Instruments

Meter Instruments

  1. MODE Button
  2. RESET Button
  3. Left Turn Signal Indicator Light
  4. Tachometer
  5. ABS Indicator Light (only on ABS model)
  6. High Beam Indicator Light
  7. Neutral Indicator Light
  8. Right Turn Signal Indicator Light
  9. Digital Meter
  10. Warning Indicator Light
